A7B

< Back

Financing & Insurance
See our Offers

Overview

Includes direct drive unit, hydraulic lines with quick disconnects, mounting bracket, hardware and two inch HEX output shaft.

Units:
Drive shaft torque @ max pressure 815.0 lb ft 1105.0 N·m Less
Drive method Gerotor Motor - Direct Gerotor Motor - Direct Less
Mounting bracket design Mini Hydraulic Excavator Mini Hydraulic Excavator Less
Maximum hydraulic flow 20.0 gal/min 75.0 L/min Less
Maximum hydraulic pressure 2988.0 psi 206.0 bar Less
Overall width w/bracket 11.0 in 282.0 mm Less
Overall drive height 35.5 in 902.0 mm Less
Housing diameter 10.0 in 252.0 mm Less
Swing range 36.0 Degrees 36.0 Degrees Less
Drive unit wt. w/ hyd. lines w/o bits 163.0 lb 74.0 kg Less
Total weight w/o bits 179.0 lb 81.0 kg Less
HEX output shaft 2.0 in 51.0 mm Less
Bit speed (drive shaft) @ max flow 191.0 RPM 191.0 RPM Less
Auger bit retention Cross bolt/nuts Cross bolt/nuts Less

Four Auger Sizes

Caterpillar offers four auger models: the direct-drive A7 Auger for the Mini Hydraulic Excavator, the chain-driven A14B Auger for the Mini Hydraulic Excavator, Multi Terrain Loader and the Skid Steer Loader, the planetary-driven A19B Auger for the Mini Hydraulic Excavator, Multi Terrain Loader and the Skid Steer Loader and the planetary-driven high flow A26B Auger for the Skid Steer Loader.
