Log & Lumber Fork Tines 1219 mm (48 in)

Request A Price Click for Price

Key Specs

Overall Length: 103.5 in; 1399 mm

Length: 96 in; 1219 mm

Width: 7.1 in; 150 mm

1219 mm (48 in)
Change model

Overview

Extra fork tines add versatility to log and lumber fork carriages, providing several styles and lengths to meet your needs.

Features At A Glance

Cat® Log & Lumber Fork Tines are used to load, unload, move deck, sort and feed the mill. Their flat fork tines and raised guards are designed specifically for use in handling both unfinished logs and stacked lumber.

Increased tine drop provides increased visibility for truck loading.

Tapered box tines are tapered to a point enabling the operator to insert the tines between logs for sorting and assist in a more controlled unloading of the payload.

Wider tine widths provide a larger surface area for stability when transporting larger materials.

Product Specifications for 1219 mm (48 in)

Overall Length	103.5 in 1399 mm
Length	96 in 1219 mm
Width	7.1 in 150 mm
Height	40 in 1016 mm
Tine Thickness	3 in 65 mm
Load Capacity	8558.3 lb 4400 kg
Weight	718.7 lb 162 kg
Tine Configuration	Non-swinging, Non-Floating Non-swinging, Non-Floating

Product Specifications for 1219 mm (48 in)

Download Print

Overall Length	103.5 in 1399 mm
Length	96 in 1219 mm
Width	7.1 in 150 mm
Height	40 in 1016 mm
Tine Thickness	3 in 65 mm
Load Capacity	8558.3 lb 4400 kg
Weight	718.7 lb 162 kg
Tine Configuration	Non-swinging, Non-Floating Non-swinging, Non-Floating
