Cold Planers PC45

Request A Price Shop Now

Key Specs

Working Width: 17.7 in; 450 mm

Maximum Cutting Depth: 5.9 in; 150 mm

Required Hydraulics: 1st Auxiliary; 1st Auxiliary

PC45
Change model

Overview

High speed drum and conical bits quickly remove asphalt and concrete prior to resurfacing.

Features At A Glance

Max Pro Pressure Gauge provides operator feedback to adjust ground speed for maximum productivity in changing material loads. Gauge displays planer performance in real-time conditions and is visible from the cab. Standard on all models.

Allows the operator to easily adjust the depth using the provided hand crank and indicator scale.

Indicates contact point of drum with surface based on depth of cut, so an assistant can communicate with the operator when to start and stop the cut.

Indicates center of the drum on the side of the planer.

Indicates the width of the cut of the drum.

Gear motor provides optimal performance and efficiency.

Easily replaceable, wear-resistant skid shoes remain parallel to the ground for optimum stability.

Hose guides ensure hydraulic lines are out of the way during all operating orientations.

Common bolt pattern allows the work tool to be interchangeable with multiple compatible machines, utilizing Cat hammer brackets.

All purpose conical bits are standard. Optional concrete bits, heavy duty concrete bits, and heavy duty asphalt bits are also available. Tools to change out the bits are included.

Product Specifications for PC45

Working Width	17.7 in 450 mm
Maximum Cutting Depth	5.9 in 150 mm
Required Hydraulics	1st Auxiliary 1st Auxiliary
Overall Width	37.1 in 943 mm
Overall Length	37.3 in 947 mm
Overall Height	34.1 in 866 mm
Weight	1468.3 lb 666 kg
Optimal Hydraulic Flow	75-140 L/min (20-37 gpm) 75-140 L/min (20-37 gpm)
Optimal Hydraulic Pressure	150-250 bar (2175-3625 psi) 150-250 bar (2175-3625 psi)
Drum Speed	220 RPM 220 RPM
Maximum Drum Width	17.7 in 450 mm
Conical Bits	48 48
Standard Bit Type	All Purpose All Purpose
