Engine
| Engine Power (ISO 14396) | 196 hp 147 kW |
| Bore | 4.1 in 105 mm |
| Derating Altitude | 9842 ft 3000 m |
| Displacement | 427.8 in³ 7.01 l |
| Emissions | U.S. EPA Tier 4 Final/EU Stage V U.S. EPA Tier 4 Final/EU Stage V |
| Engine Model | Cat 7.1 Cat 7.1 |
| Engine RPM | 2,200 2,200 |
| Standard Capability | 109 °F 43 °C |
| High - Ambient Capability | 122 °F 50 °C |
| Maximum Torque - ISO 9249 | 616 lb/ft 835 N·m |
| Stroke | 5.3 in 135 mm |
| Torque Rise - ISO 9294 | 40% 40% |
| Number of Cylinders | 6 6 |
| Note (1) | Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 standards in effect at the time of manufacture. Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 standards in effect at the time of manufacture. |
| Note (2) | Net power advertised is the power available at rated speed of 2,200 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator. Net power advertised is the power available at rated speed of 2,200 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator. |
| Note (3) | Power as declared per ISO 14396 Power as declared per ISO 14396 |
| Engine Power AWD (ISO 14396) | 196 hp 147 kW |
