Drills MD6380
Request A Price Find DealerKey Specs
- Pull-Down Capacity
- Up to 49 895 kg (110,000 lb)
- Up to 49 895 kg (110,000 lb)
- Hole Diameter
- 251-381 mm (9.875-15 in)
- 251-381 mm (9.875-15 in)
- Engine
- Cat® 3512C
- Cat® 3512C
Overview
Smart. Precise. Powerful.
Designed for large bore hole production drilling in very hard rock, the ultra-class Cat® MD6380 provides the optimal mix of on-board air, feed force, rotary torque and machine mobility. It’s a powerful, rugged machine that can stand up to the conditions of any site and deliver reliable performance with high availability. Robust structures and mast with an integral a-frame allow it to stand up to the toughest conditions, so it delivers long life and reliable performance. With a next-generation cab and operator station, the MD6380 is designed to keep operators comfortable and productive all shift long. Designed to drill holes from 251-381 mm (9.875-15 in) in diameter, the MD6380 is is optimized for single-pass or multi-pass drilling in both rotary and down-the-hole drilling modes.
Benefits
Enhanced By Technology
Onboard health monitoring and drill assist and factory-ready for Cat® MineStar autonomy
World-Class Maneuverability
Compact working envelope, faster set-up, low center of gravity and excavator-style undercarriage
Exceptional Visibility
Cab enhanced with large windows, interior lights and high-resolution camera monitor
Features At A Glance
- Ergonomic controls to help operators stay alert and avoid fatigue
- Multifunction joystick controls and touchscreen monitors are easy to use and intuitive
- Excellent visibility, thanks to multiple cameras and full-length windows
- Optional heated and ventilated seat for enhanced operator comfort
- Cat to the core, with common parts and components and consistent design characteristics across all Cat drill models
- Shared software for autonomous features
- Backed by the world-class support of the Cat dealer network
- Common electronic architecture across all Cat machines to ensure technician familiarity
- Cat Electronic Technician (Cat ET) enables fast and easy troubleshooting
- Serves as common platform for integrating future autonomy solutions
- Product Link™ Elite provides real-time performance tracking
- Variable air volume for reduced fuel consumption and powerful performance
- C27 engine matched to largest “standard” compressor in this class for fast cycle times
- Powertrain optimized to withstand rigorous drilling applications
- High- and low-pressure configurations offer variable volume air control
- Optimal feed force, rotary torque and air, helping to reduce fuel consumption
- Integrated Drill Assist functionality, including auto level, auto retract jacks, auto raise and lower mast, and auto drill
- Machine health and performance monitoring keep machine running productively
- Drill depth meter helps reduce over- and under-drilling
- Ready to connect with the Cat MineStar™ suite of technologies, including Terrain for drilling and Command for drilling
- Four standard cameras give the operator excellent visibility: left, right and front view when tramming; carousel view when pipe handling; all three view simultaneously
- Exterior lighting packages have spot and flood lights positioned to illuminate paths for ingress/egress and major service points
- MineStar Command for drilling enables remote or autonomous operation — removing operator from the machine
- Designed to use less fuel, which reduces engine emissions
- Reduced waste and lower owning and operating costs thanks to increased commonality of systems and components, plus a reduction in unique part numbers.
- Longer maintenance intervals that decrease the amount of waste contributed to the environment.
Product Specifications for MD6380
Specifications
| Hole Diameter | 251-381 mm (9.875-15 in) 251-381 mm (9.875-15 in) |
| Engine | Cat® 3512C Cat® 3512C |
| Bit Load | Up to 53 845 kg (118,719 lb) Up to 53 845 kg (118,719 lb) |
Engine
| Power Rating (ISO 14396) | 1273 hp 949 kW |
| Emissions (1) | U.S. EPA Tier 2/EU Stage II equivalent U.S. EPA Tier 2/EU Stage II equivalent |
| Power Rating (J1995) | 1287 hp 960 kW |
| Engine | Cat® 3512C @ 1,800 rpm Cat® 3512C @ 1,800 rpm |
Compressor/Receiver Tank
| Choice | Rotary, single stage, low pressure 101.9 m³/min (3,600 ft³/min) @ 6.9 bar (100 psi); with low pressure receiver tank for ASME/CRN/AU or CE Rotary, single stage, low pressure 101.9 m³/min (3,600 ft³/min) @ 6.9 bar (100 psi); with low pressure receiver tank for ASME/CRN/AU or CE |
Cooling
| Features | Functional in ambient temperature of 52° C (125° F) Functional in ambient temperature of 52° C (125° F) |
Undercarriage
| Cat 374 EEL - Double Grousers for Hard Rock Applications | 29.5 in 750 mm |
| Cat 374 EEL - Drawbar Pull | 723316 lbf 980686 N·m |
| Cat 374 EEL - Double Grousers for Soft Rock Applications | 35.4 in 900 mm |
Hydraulics
| Components (1) | Two (2) primary pumps – 280 cc (piston with proportional electronic controls) Two (2) primary pumps – 280 cc (piston with proportional electronic controls) |
| Components (2) | One (1) auxiliary circuit pump – 145 cc (piston, load sensing) One (1) auxiliary circuit pump – 145 cc (piston, load sensing) |
| Components (3) | Two (2) fan pumps – 100 cc (piston with proportional electronic controls) Two (2) fan pumps – 100 cc (piston with proportional electronic controls) |
| Components (4) | Two (2) charge pumps – 74 cc (fixed displacement) Two (2) charge pumps – 74 cc (fixed displacement) |
| Components (5) | Scheduled Oil Sampling (S·O·SSM) ports Scheduled Oil Sampling (S·O·SSM) ports |
Mast
| Note (1) | Vertical or angle drilling Vertical or angle drilling |
| Hole Diameter Range | 251-381 mm (9.875-15 in) 251-381 mm (9.875-15 in) |
| Pull Down Capacity Up To | 110000 lb 49895 kg |
| Bit Load Up To | 118719 lb 53845 kg |
| Rotation Torque Up To | 15400 lbf 20880 N·m |
| Single Pass Hole Depth Down To | 65 ft 19.8 m |
| Multi-Pass Hole Depth Down To | 129 ft 39.5 m |
Mast Accessories
| Accessory (1) | Pipe positioner (stabilizer) engaged/disengaged indicator, and interlock Pipe positioner (stabilizer) engaged/disengaged indicator, and interlock |
| Accessory (2) | One hydraulic pipe catcher One hydraulic pipe catcher |
| Accessory (3) | Hydraulic pipe support in the upper section of the mast Hydraulic pipe support in the upper section of the mast |
Pipe Loader
| Feature | LH/RH pipe racks hold 9.906 m (32.5 ft) drill pipe LH/RH pipe racks hold 9.906 m (32.5 ft) drill pipe |
| 324 mm (12.75 in) diameter |
– Single pipe rack – Dust collector side only – Single pass only – Single pipe rack – Dust collector side only – Single pass only |
| 340 mm (13.375 in) diameter |
– Single pipe rack – Dust collector side only – Single pass only – Single pipe rack – Dust collector side only – Single pass only |
| 219 mm (8.625 in) diameter |
– LH and RH, double pipe rack – Capable of single and multi-pass – Primary loader @ 29.68 m (97.4 ft) – Secondary loader @ 39.59 m (129.9 ft) – LH and RH, double pipe rack – Capable of single and multi-pass – Primary loader @ 29.68 m (97.4 ft) – Secondary loader @ 39.59 m (129.9 ft) |
| 273 mm (10.75 in) diameter |
– LH and RH, double pipe rack – Capable of single and multi-pass – Primary loader @ 29.68 m (97.4 ft) – Secondary loader @ 39.59 m (129.9 ft) – LH and RH, double pipe rack – Capable of single and multi-pass – Primary loader @ 29.68 m (97.4 ft) – Secondary loader @ 39.59 m (129.9 ft) |
| 235 mm (9.25 in) diameter |
– LH and RH, double pipe rack – Capable of single and multi-pass – Primary loader @ 29.68 m (97.4 ft) – Secondary loader @ 39.59 m (129.9 ft) – LH and RH, double pipe rack – Capable of single and multi-pass – Primary loader @ 29.68 m (97.4 ft) – Secondary loader @ 39.59 m (129.9 ft) |
Break Out Wrench
| Variable Grip |
– 219, 235, 273 mm (8.625, 9.25, 10.75 in) – 324, 340 mm (12.75, 13.375 in) – 219, 235, 273 mm (8.625, 9.25, 10.75 in) – 324, 340 mm (12.75, 13.375 in) |
Drill Tool Package
| One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal |
– 219 mm (8.625 in) – 235 mm (9.25 in) – 273 mm (10.75 in) – 324 mm (12.75 in) – 340 mm (13.375 in) – 219 mm (8.625 in) – 235 mm (9.25 in) – 273 mm (10.75 in) – 324 mm (12.75 in) – 340 mm (13.375 in) |
Subs
| Shock absorber with top sub adapter - available in Standard or Premium |
– 219 mm (8.625 in) – 235 mm (9.25 in) – 273 mm (10.75 in) – 324 mm (12.75 in) – 340 mm (13.375 in) – 219 mm (8.625 in) – 235 mm (9.25 in) – 273 mm (10.75 in) – 324 mm (12.75 in) – 340 mm (13.375 in) |
Operator Environment
| Cab - Premium |
– Includes a leather seat with heat and ventilation, heavy duty suspension, dual pane window glass – Additional storage plus windshield wipers on front and rear windows – Removable driller window guard plus front window guard and trainer seat – Includes a leather seat with heat and ventilation, heavy duty suspension, dual pane window glass – Additional storage plus windshield wipers on front and rear windows – Removable driller window guard plus front window guard and trainer seat |
| Cab - Standard | – Includes a fabric seat, single pane window glass, shades, and a windshield wiper for driller window, removable driller window guard and a trainer seat – Includes a fabric seat, single pane window glass, shades, and a windshield wiper for driller window, removable driller window guard and a trainer seat |
Fluids
| Service Package - Standard |
– Fast fill fuel and water only – Automated lubricant system – Fast fill fuel and water only – Automated lubricant system |
| Service Package - Premium |
– Service center for lubricant drain and fill – Fast fill fuel and water – Automated lubricant system – Service center for lubricant drain and fill – Fast fill fuel and water – Automated lubricant system |
Dust Suppression
| Water Injection System | 600 gal (US) 2271 l |
| Water Injection System, High Volume Total Tank Capacity | 1400 gal (US) 5299 l |
| Water Injection System, High Volume Total Tank Capacity (Note 1) | 2271 L (600 gal) below deck mounted tank 2271 L (600 gal) below deck mounted tank |
| Water Injection System (Note 1) | Tank below deck Tank below deck |
| Water Injection/Dry Dust Collection | 600 gal (US) 2271 l |
| Water Injection System, High Volume Total Tank Capacity (Note 2) | 3028 L (800 gal) above deck mounted tank 3028 L (800 gal) above deck mounted tank |
| Water Injection System (Note 2) | Fast fill Fast fill |
| Water Injection/Dry Dust Collection (Note 2) | Fast fill Fast fill |
| Water Injection/Dry Dust Collection (Note 1) | Tank below deck Tank below deck |
| Water Injection/Dry Dust Collection (Note 3) | 204 m³/min (7,200 ft³/min) dry dust collection 204 m³/min (7,200 ft³/min) dry dust collection |
| Water Injection System, High Volume Total Tank Capacity (Note 3) | Fast fill Fast fill |
Batteries
| Note (2) |
Six (6) each batteries, sealed – Required for semi/full autonomy packages Six (6) each batteries, sealed – Required for semi/full autonomy packages |
| Note (1) | Four (4) each batteries, sealed Four (4) each batteries, sealed |
Climate Choices
| Climate Level 1 Standard Fluids and Lubricants (1) | – Temperature range of –1° C (30° F) to 52° C (125° F) – Temperature range of –1° C (30° F) to 52° C (125° F) |
| Climate Level 2 Arctic Fluids and Lubricants | – Temperatures down to –18° C (–0.4° F) – Temperatures down to –18° C (–0.4° F) |
Automation and Technology
| Components (6) | Product Link™ Product Link™ |
| Components (5) | Electric controls for drilling, tramming, leveling plus auxiliary functions Electric controls for drilling, tramming, leveling plus auxiliary functions |
| Type (1) | Radio-ready for communication and entertainment radio Radio-ready for communication and entertainment radio |
| Type (2) | Integrated Terrain for Drilling complete with wiring and harnesses Integrated Terrain for Drilling complete with wiring and harnesses |
| Components (1) | Single pass auto drill/drill assist Single pass auto drill/drill assist |
| Components (2) | Multi pass auto drill/drill assist Multi pass auto drill/drill assist |
| Components (3) | Drill depth meter Drill depth meter |
| Components (4) | Auto level, auto retract jacks, auto raise and lower mast Auto level, auto retract jacks, auto raise and lower mast |
Dimensions (Approximate)
| Height mast up | 87.6 ft 26.7 m |
| Height mast down | 21.7 ft 6.6 m |
| Length mast down | 92.9 ft 28.3 m |
| Note | *Working Length Mast Up with bolt-on platform adds 1.2 m (4 ft) for total of 15.9 m (52.1 ft) *Working Length Mast Up with bolt-on platform adds 1.2 m (4 ft) for total of 15.9 m (52.1 ft) |
| Working Width (non-drill end) | 19.9 ft 6.06 m |
| Working Width (drill end) | 22.6 ft 6.89 m |
| Mast Only Shipping Length | 82.8 ft 25.24 m |
| Working Length Mast Up* | 48.1 ft 14.7 m |
Weights
| Mast Only | 88184 lb 40000 kg |
| Without Mast | 225533 lb 102300 kg |
| Working Weight Range | 142 300 kg (313,717 lb) 142 300 kg (313,717 lb) |
MD6380 Standard Equipment
POWER TRAIN
- Receiver tank for ASME/CRN/AU or CE receiver tank
CAB
- Standard cab
– Includes a fabric seat, single pane window glass, shades, and a windshield wiper for driller window, removable driller window guard and a trainer seat
- Viewing hatch to spot over the hole
- LED lighting
CONTROLS
- Basic drill depth indicator and interlocks
PRODUCT LINK/TERRAIN
- Product Link (Cellular)
MAST
- No mast access/handrail only
PIPE LOADER (SELECT ONE)
- 219 mm (8.625 in) diameter
– Two pipe rack
– Capable of single and multi-pass
- 235 mm (9.25 in) diameter
– Two pipe rack
– Capable of single and multi-pass
- 273 mm (10.75 in) diameter
– Two pipe rack
– Capable of single and multi-pass
- 324 mm (12.75 in) diameter
– Single pipe rack
– Dust collector side only
– Single pass only
- 340 mm (13.375 in) diameter
– Single pipe rack
– Dust collector side only
– Single pass only
TOP SUB/SHOCK SUB (SELECT ONE)
- 219 mm (8.625 in) standard
- 235 mm (9.25 in) standard
- 273 mm (10.75 in) standard
- 324 mm (12.75 in) standard
- 340 mm (13.375 in) standard
TOOL GROUPS (SELECT ONE)
- 219 mm (8.625 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
- 235 mm (9.25 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
- 273 mm (10.75 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
- 324 mm (12.75 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
- 340 mm (13.375 in)
– One piece roller deck bushing, pipe positioner, deck wrench, bit sub, pipe wiper seal
VARIABLE GRIP HYDRAULIC BREAKOUT WRENCH (SELECT ONE)
- Grip range
– 219, 235, 273 mm (8.625, 9.25, 10.75 in)
- Grip range
– 324, 340 mm (12.75, 13.375 in)
DRILL PIPE – 9.9 M (32.5 FT) LENGTH
- No pipe thread greaser
TRICONE BITS GROUP (SELECT ONE)
- Hydraulic bit basket
SERVICE PACKAGES/FLUID SYSTEM
- Standard fast fill for fuel and water only, automated lubricant system
CLIMATE/REGIONAL CONSIDERATIONS
- Air receiver tank low pressure (ASME/CRN/AU) or
- Air receiver tank low pressure (CE)
- Four (4) batteries
- Climate Level 1
– Standard fluids and lubricants
– With a temperature range of –1° C (30° F) to 52° C (125° F)
- Certifications CE
FRAME/DECK
- No tool storage box (cover only)
- No jib crane (cover only)
DUST SUPPRESSION
- Water injection only (no dust collector)
– 2271 L (600 gal) tank below deck
UNDERCARRIAGE (SELECT ONE)
- 750 mm (29.5 in) double grousers for hard rock applications or
- 900 mm (35.4 in) double grousers for soft rock applications
MD6380 Optional Equipment
CAB
- Premium cab
– Includes a leather seat with heat and ventilation, heavy duty suspension, dual pane window glass
– Additional storage plus windshield wipers on front and rear windows, a removable driller window guard plus front window guard and a trainer seat
- Cab roof access system (includes ladders, cage and rails)
- Lights for tram (front and cab)
CONTROLS
- Auto Drill Assist
– Single pass auto drill
- Auto Drill Assist
– Multi pass auto drill
- Manometer/pressure gauge
- Remote tram
PRODUCT LINK/TERRAIN
- Product Link (Satellite)
- Product Link (Dual)
- Terrain (Guidance)
MAST
- Mast Access Arrangement
– Includes steps, guardrails, landing platforms, and walkway
- Drill pipe thread greaser
- Tool Lubrication System
– Rotary tricone, 113.5 L (30 gal)
- Flashing beacon for mast clearance
- Overhead winch assembly
– Includes cable and hook plus remote
TOP SUB/SHOCK SUB (SELECT ONE)
- 219 mm (8.625 in) premium
- 235 mm (9.25 in) premium
- 273 mm (10.75 in) premium
- 324 mm (12.75 in) premium
- 340 mm (13.375 in) premium
DRILL PIPE – 9.9 M (32.5 FT) LENGTH
- 219 mm (8.625 in) diameter
- 235 mm (9.25 in) diameter
- 273 mm (10.75 in) diameter
- 324 mm (12.75 in) diameter
- 340 mm (13.375 in) diameter
- Pipe thread greaser
TRICONE BITS GROUP (SELECT ONE)
- 9.875 in (251 mm) tricone bit
- 10.625 in (270 mm) tricone bit
- 12.25 in (311 mm) tricone bit
- Bit lock plate 251 mm (9.875 in)
- Bit lock plate 270 mm (10.625 in)
- Bit lock plate 311 mm (12.25 in)
- Bit lock plate 349 mm (13.75 in)
- Bit lock plate 381 mm (15 in)
SERVICE TOOLS
- Lifting bail 152 mm (6 in) BECO for 194‑235 mm (7.625-9.25 in) pipe
- Lifting bail 203 mm (8 in) BECO for 273‑324 mm (10.75-12.75 in) pipe
- Lifting bail 254 mm (10 in) BECO for 340 mm (13.375 in) pipe
- Lifting bail 168 mm (6.625 in) API regular thread for 251-349 mm (9.875‑13.75 in) tricone bit
- Lifting bail 178 mm (7.0 in) API regular thread for 381 mm (15 in) tricone bit
- Bushing retainment tool (8.625-10.75 in pipe) (6 in, 7 in and 7.8 in flats)
- Bushing retainment tool (12.75-13.378 in pipe) (10.5 in and 11.38 in flats)
SERVICE PACKAGES/FLUID SYSTEM
- Premium with Service Center for lubricant drain and fill; automated lubricant system, fast fill fuel and water
CLIMATE/REGIONAL CONSIDERATIONS
- Six (6) batteries (required for autonomy packages)
- Climate Level 2
– Arctic fluids and lubricants
– Temperatures down to –18° C (–0.4° F)
FRAME/DECK
- Tool storage box
- Jib crane pedestal only
- Blowdown lines and nozzle (with quick connect cooler end and drill deck)
DUST SUPPRESSION
- Water injection and dust collector
– 2271 L (600 gal) tank below deck
– 204 m³/min (7,200 ft³/min) dry dust collection
- High capacity water injection
– 5299 L (1,400 gal)- 2271 L (600 gal) below-deck mounted tank and a 3028 L (800 gal) above deck mounted tank
- Dust curtain hydraulic lifters
– Front and rear dust curtains (recommended with dust collector)
- Tram-off Spray System
Compatible Technology and Services
Leverage Caterpillar connected data and security principles to improve efficiencies, increase productivity and make your business more profitable.
Command
Fleet
Health
Terrain
-
Cat Command for Drilling
Cat® MineStar™ Command for drilling delivers cost-effective, high precision drilling through automation — which will ultimately reduce operating costs, increase safety and improve productivity. Command for drilling ensures that every hole is accurately placed, drilled to the proper elevation and angle, and able to stand up until blasting. A range of capabilities lets site managers configure and automate the drilling system to their budgets and needs. From predrill planning to blasting, Command impacts the bottom line all the way through the crusher and mill.
1
-
8
of
9 Items
items
Cat® MineStar™ Command for drilling delivers cost-effective, high precision drilling through automation — which will ultimately reduce operating costs, increase safety and improve productivity. Command for drilling ensures that every hole is accurately placed, drilled to the proper elevation and angle, and able to stand up until blasting. A range of capabilities lets site managers configure and automate the drilling system to their budgets and needs. From predrill planning to blasting, Command impacts the bottom line all the way through the crusher and mill.
-
Cat Fleet for Surface
Cat® MineStar Fleet is the single best source for fleet management information. An integrated fleet monitoring and management system, it can be used with any machine or system to measure, manage and maximize every facet of an operation, no matter the size or type. Fleet provides real-time visibility to cycle time, payload and other key operational parameters. It monitors machine locations and material movement and provides alerts of misroutes to ensure material is moved to the proper location.
1
-
8
of
9 Items
items
Cat® MineStar Fleet is the single best source for fleet management information. An integrated fleet monitoring and management system, it can be used with any machine or system to measure, manage and maximize every facet of an operation, no matter the size or type. Fleet provides real-time visibility to cycle time, payload and other key operational parameters. It monitors machine locations and material movement and provides alerts of misroutes to ensure material is moved to the proper location.
-
Cat Health
Through regular monitoring of machine conditions, mines can adopt a more proactive approach to maintenance and repair. Equipment health data is a key contributor to that approach. Data helps mines identify equipment problems long before failure.
Accessing the right data at the right time is critical to improving operational intelligence and machine predictive analysis. Cat® MineStar™ Health helps you meet that need by connecting you to your machines and delivering that important information. The MineStar Health portfolio set consists of Connectivity Enablers that collect, convert and transmit equipment data; and Applications that visualize, analyze and report health equipment data.
1
-
8
of
9 Items
items
Through regular monitoring of machine conditions, mines can adopt a more proactive approach to maintenance and repair. Equipment health data is a key contributor to that approach. Data helps mines identify equipment problems long before failure.
Accessing the right data at the right time is critical to improving operational intelligence and machine predictive analysis. Cat® MineStar™ Health helps you meet that need by connecting you to your machines and delivering that important information. The MineStar Health portfolio set consists of Connectivity Enablers that collect, convert and transmit equipment data; and Applications that visualize, analyze and report health equipment data.
-
Cat Terrain for Drilling
Effective mining starts with accurate drilling. That means drilling every hole precisely to plan, at the proper angle and the correct depth. Cat® MineStar™ Terrain for drilling provides precision guidance that helps operators complete patterns accurately and productively. It pays other dividends, as well, by improving safety, reducing costs and recording data about drilled stratification to aid in planning blasts and improving fragmentation. And it works with all brands of drills and communicates seamlessly with MineStar and other mine management systems.
1
-
8
of
9 Items
items
Effective mining starts with accurate drilling. That means drilling every hole precisely to plan, at the proper angle and the correct depth. Cat® MineStar™ Terrain for drilling provides precision guidance that helps operators complete patterns accurately and productively. It pays other dividends, as well, by improving safety, reducing costs and recording data about drilled stratification to aid in planning blasts and improving fragmentation. And it works with all brands of drills and communicates seamlessly with MineStar and other mine management systems.
assignment Product Brochures and More Are Ready to Download!
Full specifications, product brochures and more. Sign up below for additional information. Or for instant access, you can skip this form.
Take the interactive virtual product tour to explore the great features and benefits of the MD6380
Start MD6380 Tour
close
Media Gallery
Photos
Videos
360 View
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
MD6380 Rotary Drill
Cat MD6380 Overview Video
Cat Rotary Drills —— Next Level
See how MD6380 compares against frequently compared products.
Drills
MD6380
Selected
- Pull-Down Capacity
- Up to 49 895 kg (110,000 lb)
- Up to 49 895 kg (110,000 lb)
- Hole Diameter
- 251-381 mm (9.875-15 in)
- 251-381 mm (9.875-15 in)
- Engine
- Cat® 3512C
- Cat® 3512C
Drills
MD6640
- Bit Load
- up to 64 000 kg (up to 141,096 lb)
- up to 64 000 kg (up to 141,096 lb)
- Hole Diameter
- 270 - 406 mm (10.625 - 16 in)
- 270 - 406 mm (10.625 - 16 in)
- Engine
- AC Induction Motor - Dual Shaft 597 kW (800 hp)
- AC Induction Motor - Dual Shaft 597 kW (800 hp)
Drills
MD6310
- Pull-Down Capacity
- Up to 39 009 kg (86,000 lb)
- Up to 39 009 kg (86,000 lb)
- Hole Diameter
- 229-311 mm (9-12.25 in)
- 229-311 mm (9-12.25 in)
- Engine
- Cat® C32B
- Cat® C32B
