Designed to remove stumps in residential, commercial and agricultural settings.
|Required Hydraulics||Standard Flow Standard Flow||More Less|
|Cutting Wheel Diameter - With Teeth||22.0 in 547.0 mm||More Less|
|Motor Displacement||4.9 in³ 80.0 cm³||More Less|
|Cutting Wheel Width - With Teeth||3.3 in 83.0 mm||More Less|
|Overall Width||46.0 in 1175.0 mm||More Less|
|Cutting Height - Above Ground||18.5 in 470.0 mm||More Less|
|Drive Shaft Torque at Maximum Pressure||218.0 lb/ft 295.0 N·m||More Less|
|Required Hydraulic Flow||42-86 L/min (11-23 gpm) 42-86 L/min (11-23 gpm)||More Less|
|Cutting Head Extension||11.0 in 280.0 mm||More Less|
|Cutting Depth - Below Ground||20.5 in 521.0 mm||More Less|
|Weight||775.0 lb 379.0 kg||More Less|
|Cutting Head Swing Range||70 degrees 70 degrees||More Less|
|Overall Height||30.0 in 730.0 mm||More Less|
|Cutting Width - Full Swing Range||60.0 in 1524.0 mm||More Less|
|Cutting Head Speed at Maximum Flow||993 rpm 993 rpm||More Less|
|Drive Method||Gerotor Motor- Direct Gerotor Motor- Direct||More Less|
|Optimal Hydraulic Pressure||145-235 bar (2100-3400 psi) 145-235 bar (2100-3400 psi)||More Less|
|Overall Length||69.0 in 1737.0 mm||More Less|
|Number of Carbide Teeth per Cutting Wheel||32 32||More Less|
Designed to economically remove stumps in residential, commercial and agricultural settings. Offers increased production over tow-behind grinders in situations where multiple stump removal is required.
Direct drive system features a variable speed, unidirectional, gerotor style motor for optimal cutting wheel speed and high torque for efficient grinding performance.
Heavy-duty cutting wheel and 32 bolt-on and replaceable carbide teeth provide maximum durability and cutting efficiency.
Adjustable cutting wheel swing, extension and depth for superior operator control.
Swing and extension are controlled hydraulically from the operator's compartment using an electro-hydraulic valve for greater productivity and swing cycle time efficiency.
Heavy-duty, dual height, pivoting stand feet provide a stable platform when grinding. Feet are adjustable to compensate for specific machine coupler-to-ground height and tire diameters.
