SE50 VT (A42) Tamper Bar Screed

Screeds SE50 VT (A42) Tamper Bar Screed

Request A Price Find Dealer

Key Specs

Standard Weight
6898 lb
3129 kg
Standard Paving Range
2.55 - 5 m (8' 4" - 16' 4")
2.55 - 5 m (8' 4" - 16' 4")
Maximum Paving Range
25 ft
7.64 m

Overview

Quality Paving

The Cat® SE50 VT screed utilizes tamper bars and rear-mounted extenders to deliver smooth material flow and increased mat density. Stability, easy set-up, and a versatile paving range make it the perfect match for air-ports, interstates, highways, and many other mid-sized paving applications.

Benefits

Advanced Technology

Optional Pave Start Assistant saves set-up profiles for repeatable use on future job sites, simply activate the profile for quick, single person setup.

High Quality Paving

The two amplitude, variable frequency tamper system combines with dual-carriage extenders to provide performance and stability.

Simple Operation

Multiple language options, two-speed extender control, and ratio adjustment for the augers and conveyors simplify operation.

Features At A Glance

Specifications Standard Equipment Optional Equipment

Product Specifications for SE50 VT (A42) Tamper Bar Screed

Download Print
Standard Weight 6898 lb 3129 kg
Standard Paving Range 2.55 - 5 m (8' 4" - 16' 4") 2.55 - 5 m (8' 4" - 16' 4")
Maximum Paving Range 25 ft 7.64 m
Tamper Speed Range 300 to 1800 rpm 300 to 1800 rpm
Vibrator Speed Range 0 to 3000 rpm 0 to 3000 rpm
Maximum Paving Depth 12 in 305 m
Crown Range -2% to +5% per side -2% to +5% per side
Extender Height Range -5 mm to +15 mm -5 mm to +15 mm
Minimum Width - Endgates Attached 106 in 2700 mm
Screed Plate Width - Front to Back 12.75 in 324 mm
Length - Front to Back, Endgates Attached 82 in 2089 mm
Length - Front to Back, Endgates Removed 62 in 1586 mm
Screed Plates Thickness 0.5 in 12.2 mm

SE50 VT (A42) Tamper Bar Screed Standard Equipment

Print

Service and Maintenance

  • Service repair kits

Safety

  • Horn_warning

Material Delivery

  • Crown
  • Endgate_manual
  • Thickness screws

SE50 VT (A42) Tamper Bar Screed Optional Equipment

Print

Technology

  • Pave Start Assistant
  • Cat Grade Control

Operating Environment

  • Umbrella
  • Visor_LCD display

Safety

  • Lights_roading

Material Delivery

  • Drop arm spacer
  • End gate_power
  • Extension Packages
  • Folding Endgate
  • Heated Endgate
  • Cutoff Shoe
  • Shoe_edge
  • Shoe_safety edge
  • Shoe_wide
