High Performance Propulsion and Maneuvering Solutions C32B

Request A Price Find Dealer

Key Specs

Power Range
2000 bhp (1491 bkW)
2000 bhp (1491 bkW)
Speed Range
2300 rpm
2300 rpm
Emissions
EPA Tier 3, IMO II
EPA Tier 3, IMO II

Overview

C32B Tier 3 Recreational

All new from the block up and built on the proven C32 platform, the C32B marine engine delivers more power, more speed, more time on the water and more peace of mind. All that comes in a quieter package with only a 2% increase in weight compared to the previous model — making the C32B the right choice for new builds and repowers. Rated at 2025 mhp (2000 bhp) / 1491 bkW @ 2300 rpm, the C32B meets U.S. EPA Marine Tier 3 and IMO II emissions standards. With an E Tier rating, it can run at the full 2000hp up to 8% of the time.

Benefits

MORE POWER, SAME PACKAGE

5% power increase with only a 2% weight increase
*compared to previous model

QUIETER OPERATION

25% noise reduction with advanced unit injection system at low speeds

E TIER RATING

Run at full 2000hp up to 8% of the time

Product Specifications for C32B

Power Range 2000 bhp (1491 bkW) 2000 bhp (1491 bkW)
Speed Range 2300 rpm 2300 rpm
Emissions EPA Tier 3, IMO II EPA Tier 3, IMO II
Aspiration TTA TTA
Bore 5.71 in 145 mm
Stroke 6.38 in 162 mm
Displacement 1959 in³ 32.1 l
Rotation from Flywheel End Counterclockwise Counterclockwise
Configuration Vee 12, 4-Stroke-Cycle Diesel Vee 12, 4-Stroke-Cycle Diesel
Width 58.3 in 1482 mm
Dry Weight 6780 lb 3145 kg
Length 82.9 in 2106 mm
Height 56.9 in 1445 mm

C32B Standard Equipment

AIR INLET SYSTEM

  • Air Cleaner System with washable filter elements and fumes disposal (closed system)
  • Turbocharger, jacket water cooled
  • Turbocharger inlet, 152 mm (6 in) OD straight connection

CONTROL SYSTEM

  • Programmable Low Idle (550 - 750 rpm)
  • Electronic diagnostics and fault logging
  • Engine and transmission monitoring (speed, temperature, pressure)
  • Electronic fuel/air ratio control
  • Engine Protection Mode for extended ambient conditions
  • 70-pin customer connector (Upper front-facing customer wiring connector and Service Tool connection)
  • Throttle Input signal options

COOLING SYSTEM

  • Sea Water Aftercooled Engine
  • Jacket water pump, gear driven
  • Sea water pump, rubber impeller, gear driven
  • Sea water Pump & JW Heat Exchanger Connection: 76.2 mm (3in) OD
  • Coolant recovery system

EXHAUST SYSTEM

  • Water-cooled exhaust manifold & turbocharger
  • 4 Bolt 130 mm (5.12 in) diameter flanged outlet

FLYWHEELS & FLYWHEEL HOUSINGS

  • Flywheel Housing:

FUEL SYSTEM

  • Simplex Fuel Filters Spin-on, RH & LH service
  • Fuel connections size:
  • Plate Type Fuel Cooler (Jacket Heat Exchanger)
  • Fuel transfer pump, gear driven
  • Manual fuel priming pump
  • Hybrid fuel line design

LUBE SYSTEM

  • Simplex Oil Filters, RH or LH service
  • RH or LH service oil filler locations
  • RH or LH service dipstick
  • Oil pump, gear driven
  • Shallow Sump

MOUNTING SYSTEM

  • Front support - adjustable

POWER TAKE-OFFS

  • Front Poly-V groove pulley (Quantity 1) for auxiliary drives

GENERAL

  • Lifting eyes
  • Front damper guard
  • RH or LH service options

C32B Optional Equipment

EXHAUST SYSTEM

  • Muffler
  • Muffler Spark Arresting

CHARGING SYSTEM

  • Battery Chargers
  • Charging Alternators
  • Ammeter

FUEL SYSTEM

  • Water Separator

INSTRUMENTATION

  • Instrument Panels
  • OEM Wiring Harness
  • Engine to Engine Harness
  • Gauges
  • Transmission Sensors
  • Exhaust Temperature Sensors

LUBE SYSTEM

  • Transmission Oil Cooler

MOUNTING SYSTEM

  • Adapter Kits
  • Isolator Mounts

POWER TAKE-OFFS

  • Rear Hydraulic Pump Drive

PROTECTION SYSTEM

  • Fuel and Oil Shielding

STARTING SYSTEM

  • Electric Starting Motors - Single 24 Volt
  • Starting Aids - JW Heaters
  • Battery Sets - 24 Volt - Dry

CONTROL SYSTEM

  • Instrument Panels

PACKING

  • Engine Protective Cover
  • Storage Preservation
  • Export Packing
