Engine
| Net Power Range (Tier 3) | 130 hp 97 kW |
| Derating Altitude (AWD) | 5499 ft 1676 m |
| Maximum Torque - ISO 9249 | 606 lb/ft 822 N·m |
| Derating Altitude | 9842.5 ft 3000 m |
| Note (2) | Net power advertised is the power available at rated speed of 2,000 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator. Net power advertised is the power available at rated speed of 2,000 rpm, measured at the flywheel when engine is equipped with fan, air cleaner, muffler and alternator. |
| Maximum Torque - AWD On | 611 lb/ft 828 N·m |
| All-Wheel Drive Net Power Range (Tier 3) | 136 hp 101 kW |
| Bore | 4.1 in 105 mm |
| Displacement | 427.8 in³ 7.01 l |
| Number of Cylinders | 6 6 |
| Torque Rise - ISO 9294 | 42% 42% |
| Engine RPM | 2,000 2,000 |
| Engine Model | Cat 7.1 Cat 7.1 |
| Note (3) | Power as declared per ISO 14396 Power as declared per ISO 14396 |
| Note (1) | Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture. Net power is tested per ISO 9249, SAE J1349, and EEC 80/1269 Standards in effect at the time of manufacture. |
| Stroke | 5.3 in 135 mm |
| Standard Capability | 122 °F 50 °C |
| Emissions | China Nonroad Stage III and Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3/EU Stage IIIA China Nonroad Stage III and Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3/EU Stage IIIA |
