Engine
| Engine Power - 2,100 rpm ISO 14396:2002 | 249 hp 186 kW |
| Engine Power - 2,100 rpm ISO 14396:2002 | 253 hp (metric) 253 hp (metric) |
| Engine Model | Cat® C7.1 Cat® C7.1 |
| Gross Power - 2,100 rpm SAE J1995:2014 | 260 hp (metric) 260 hp (metric) |
| Net Power - 2,100 rpm ISO 9249:2007, SAE J1349:2011 | 231 hp 172 hp |
| Net Power - 2,100 rpm ISO 9249:2007, SAE J1349:2011 | 235 hp (metric) 235 hp (metric) |
| Engine Torque - 1,400 rpm ISO 14396:2002 | 912 lbf·ft 1236 N·m |
| Gross Torque - 1,400 rpm SAE J1995:2014 | 927 lbf·ft 1257 N·m |
| Net Torque - 1,300 rpm ISO 9249:2007, SAE J1349:2011 | 863 lbf·ft 1170 N·m |
| Displacement | 427 in³ 7.01 l |
| Emissions | Meets Brazil MAR-1 and UN ECE R96 Stage IIIA emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA. Meets Brazil MAR-1 and UN ECE R96 Stage IIIA emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA. |
| Biodiesel Capability | Up to B20¹ Up to B20¹ |
| Note (1) | The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and muffler. The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and muffler. |
| Note (2) | ¹Cat engines are compatible with diesel fuel blended with following lower carbon intensity fuels up to: • 100% biodiesel FAME (fatty acid methyl ester)* • 100% renewable diesel, HVO (hydrogenated vegetable oil) and GTL (gas-to-liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. *For use of blends higher than 20% biodiesel, consult your Cat dealer. **Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. ¹Cat engines are compatible with diesel fuel blended with following lower carbon intensity fuels up to: • 100% biodiesel FAME (fatty acid methyl ester)* • 100% renewable diesel, HVO (hydrogenated vegetable oil) and GTL (gas-to-liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. *For use of blends higher than 20% biodiesel, consult your Cat dealer. **Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. |
