Small Wheel Loaders 924

Product Specifications for 924

924 Standard Equipment

NOTE: Not all features are available in all regions.

OPERATOR ENVIRONMENT

• 75 mm (3 in) retractable seatbelt

• Automatic temperature control

• Cab, enclosed ROPS/FOPS pressurized and sound suppressed

• Push to Start

• 8 Inch Touch Screen

• Programmable Joystick

• Cup holders

• External mirrors with lower parabolic

• Ground level cab door release

• Hydraulic control lockout

• Interior cab lighting, door

• Lunch box storage

• Radio ready speakers

• Seat mounted electronic implement controls, adjustable

• Sliding glass on side window

• Column mounted multi function control lights, wipers, turn signal

• Suspension seat, fabric

• Tilt steering wheel

• Tinted front glass

• Wet arm wiper/washer, 2-speed and intermittent, front

• Wet arm wiper washer, rear

• Mounting Provision

• Digital hour meter, odometer and tachometer

• Digital ground speedometer and direction indicator

• Engine coolant temperature gauge

• Fuel and diesel exhaust fluid levels

• Hydraulic oil temperature gauge

• Fuel and diesel exhaust fluid levels

• Hydraulic oil temperature gauge

POWER TRAIN

• Cat C7.1 engine

• Auto idle shut down feature

• Auto Engine RPM

• Meets Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA.

• Turbocharged and aftercooled

• Filtered crankcase breather

• Power Modes (standard and performance)

• Dry type air cleaner

• Coolant protection to –34 °C (–29 °F)

• Fuel priming pump, automatic

• Fuel water separator

• Axle seal guards

• Enclosed wet disc full hydraulic brakes

• Parking brake, electric

• Lubed for life driveshafts

• Hydrostatic transmission with electronic control

• Operator modes (TC, Hystat, Single Pedal and Ice)

• Directional shift aggressiveness (fast, medium, slow)

• Auto Wheel Torque control, adjust wheel torque

• Creeper control, adjust ground speed

• Single plane cooling package, wide 6 fins per inch density

• Hydraulically driven demand cooling fan

• Scheduled Oil Sampling (S·O·SSM) port, engine, coolant, transmission

HYDRAULICS

• Automatic lift and bucket kickouts, adjustable in-cab

• Bucket and fork modes, adjustable in-cab

• Cylinder damping at kickout and mechanical end stops

• Fine mode control (fast, medium, slow)

• Hydraulic response setting (fast, medium, slow)

• Hydraulic diagnostic connectors and S·O·S ports

• Hydraulic sight gauge, visible

• Load sensing hydraulics and steering

• Seat mounted hydraulic joystick controls

ELECTRICAL

• Alternator, 115-amp, heavy duty

• 12V power supply in cab (2)

• Batteries, 1,000 CCA (2) 24-volt system, disconnect switch

• Back up alarm

• Emergency shutdown switch

• LED rear stop and turn lights

• Heavy duty gear reduction starter

• Product Link™

• Remote jump start post

• Resettable main and critical function breakers

• Roading lights front and rear

OTHER

• Large-access enclosure doors with adjustable close/open force

• Parallel lift loader linkage

• Recovery hitch with pin

• Remote mounted lubrication points

• Lockable compartments

924 Optional Equipment

NOTE: Not all features are available in all regions.

OPERATOR ENVIRONMENT

• Joystick steering – 25 mph (40 kph) capable

• Radio packages

• Telescoping Steering Column

• Deluxe seat – fully adjustable fabric air suspension seat with mid seat backrest

• Premium seat – fully adjustable leather and fabric air suspension with high backrest and air lumbar support. Seat is heated and ventilated on bottom cushion and backrest.

• Rear Object Detection

• Multi View Camera

• Front View Camera, roof mounted

• Heated external Mirrors (2)

• Electrically adjustable and heated external mirrors (2)

• Internal Mirrors (2)

• Sunscreen, front and rear

• Operator Not Present sytem

• Powered precleaned for cab air

• Cab guarding

POWER TRAIN

• Differential, limited slip, rear

• Differntial lock in front axle

• Powertrain Guarding

• Range of Tire Options

• Fenders (extended cover and full coverage)

HYDRAULICS

• Auxiliary flow, third and fourth function

• Connect Under Pressure Disconnects

• Ride Control System, adjustable via display

• Autolube, integrated in display

• Debris packages (low, medium, high)

ELECTRICAL

• Cold start package

• Ether starting aid, block heater and additional batteries, 1,000 CCA (4 total)

• Lights, auxiliary, halogen or LED with engine compartment lights

• Beacon light, strobe

• Light Guarding

OTHER OPTIONAL EQUIPMENT

• Coupler (Fusion)

• Heavy Counterweight

• Cat Payload Printer

• Cylinder Guarding

• Range of Work Tool Attachments
