Engine
| Engine Power - 2,100 rpm ISO 14396:2002 | 269 hp 201 kW |
| Engine Power - 2,100 rpm ISO 14396:2002 | 273 hp (metric) 273 hp (metric) |
| Engine Model | Cat® C7.1 Cat® C7.1 |
| Gross Power - 2,100 rpm SAE J1995:2014 | 273 kW 203 hp |
| Gross Power - 2,100 rpm SAE J1995:2014 | 277 hp (metric) 277 hp (metric) |
| Net Power - 2,100 rpm ISO 9249:2007, SAE J1349:2011 | 255 hp (metric) 255 hp (metric) |
| Engine Torque - 1,400 rpm ISO 14396:2002 | 918 lbf·ft 1245 N·m |
| Gross Torque - 1,400 rpm SAE J1995:2014 | 926 lbf·ft 1256 hp |
| Net Torque - 1,400 rpm ISO 9249:2007, SAE J1349:2011 | 867 lbf·ft 1176 N·m |
| Displacement | 427 in³ 7.01 l |
| Emissions | Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards. Meets U.S. EPA Tier 4 Final, EU Stage V, and Japan 2014 emission standards. |
| Biodiesel Capability | Up to B20¹ Up to B20¹ |
| Note (1) | The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and aftertreatment. The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and aftertreatment. |
| Note (2) | ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels**up to: 20% biodiesel FAME (fatty acid methyl ester) ***100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or "Caterpillar Machine Fluids Recommendations" (SEBU6250) for details. *While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use. **Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. ***Engines with no aftertreatment devices are compatible with higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer). ¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels**up to: 20% biodiesel FAME (fatty acid methyl ester) ***100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application. Please consult your Cat dealer or "Caterpillar Machine Fluids Recommendations" (SEBU6250) for details. *While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use. **Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels. ***Engines with no aftertreatment devices are compatible with higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer). |
