Engine Power - 1,700 rpm ISO 14396:2002
|
420 hp
313 kW
|
|
Engine Power - 1,700 rpm ISO 14396:2002
|
426 hp (metric)
426 hp (metric)
|
|
Engine Model
|
Cat® C13
Cat® C13
|
|
Gross Power - 1,700 rpm SAE J1995:2014
|
425 hp
317 kW
|
|
Gross Power - 1,700 rpm SAE J1995:2014
|
431 hp (metric)
431 hp (metric)
|
|
Net Power - 1,700 rpm ISO 9249:2007, SAE J1349:2011
|
393 kW
293 hp
|
|
Net Power - 1,700 rpm ISO 9249:2007, SAE J1349:2011
|
398 hp (metric)
398 hp (metric)
|
|
Engine Torque - 1,200 rpm ISO 14396:2002
|
1612 lbf·ft
2185 N·m
|
|
Gross Torque - 1,200 rpm SAE J1995:2014
|
1627 hp
2206 N·m
|
|
Net Torque - 1,100 rpm ISO 9249:2007, SAE J1349:2011
|
1539 lbf·ft
2086 N·m
|
|
Displacement
|
763 in³
12.5 l
|
|
Emissions
|
Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, and Japan 2014 emission standards.
Meets U.S. EPA Tier 4 Final, EU Stage V, Korea Stage V, and Japan 2014 emission standards.
|
|
Biodiesel Capability
|
Up to B20¹
Up to B20¹
|
|
Note (1)
|
The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and aftertreatment.
The net power advertised is the power available at the flywheel when the engine is equipped with fan, alternator, air cleaner, and aftertreatment.
|
|
Note (2)
|
¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels**up to:
20% biodiesel FAME (fatty acid methyl ester)
***100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application.
Please consult your Cat dealer or "Caterpillar Machine Fluids Recommendations" (SEBU6250) for details.
*While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use.
**Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels.
***Engines with no aftertreatment devices are compatible with higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).
¹Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) and are compatible* with ULSD blended with the following lower-carbon intensity fuels**up to:
20% biodiesel FAME (fatty acid methyl ester)
***100% renewable diesel, HVO (hydrotreated vegetable oil) and GTL (gas-to-liquid) fuels. Refer to guidelines for successful application.
Please consult your Cat dealer or "Caterpillar Machine Fluids Recommendations" (SEBU6250) for details.
*While Caterpillar engines are compatible with these alternative fuels, some regions may not allow their use.
**Tailpipe greenhouse gas emissions from lower-carbon intensity fuels are essentially the same as traditional fuels.
***Engines with no aftertreatment devices are compatible with higher blends, up to 100% biodiesel (for use of blends higher than 20% biodiesel, consult your Cat dealer).
|
|
Gross Torque @ 1,200 rpm – SAE J1995:2014
|
1627 lb/ft
2206 N·m
|
|
Engine Torque @ 1,200 rpm – ISO 14396:2002
|
1612 lb/ft
2185 N·m
|
|
Engine Power @ 1,700 rpm – ISO 14396:2002
|
420 hp
313 kW
|
|
Gross Power @ 1,700 rpm – SAE J1995:2014
|
425 hp
317 kW
|
|
Net Torque @ 1,100 rpm – ISO 9249:2007, SAE J1349:2011
|
1539 lb/ft
2086 N·m
|
|
Note (3)
|
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: • 20% biodiesel FAME (fatty acid methyl ester)* • 100% renewable diesel, HVO (hydrogenated vegetable oil) and GTL (gas-to- liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel.
Cat diesel engines are required to use ULSD (ultra-low sulfur diesel fuel with 15 ppm of sulfur or less) or ULSD blended with the following lower-carbon intensity fuels up to: • 20% biodiesel FAME (fatty acid methyl ester)* • 100% renewable diesel, HVO (hydrogenated vegetable oil) and GTL (gas-to- liquid) fuels Refer to guidelines for successful application. Please consult your Cat dealer or “Caterpillar Machine Fluids Recommendations” (SEBU6250) for details. * Engines with no aftertreatment devices can use higher blends, up to 100% biodiesel.
|
