2187 mm (86 in) w/Spill Guard, Bolt-On Cutting Edge

< Back

Financing & Insurance
See our Offers

Overview

Powerful clamping forces for grasping large, unusually shaped objects such as trees and recycling debris.

Units:
Width 86.0 in 2187.0 mm Less
Capacity 0.56 yd³ 0.43 m³ Less
Weight 1071.4 lb 486.0 kg Less
Jaw Opening 30.0 in 767.0 mm Less
Clam Angle 89.0 ° 89.0 ° Less
Base Edge Thickness 0.75 in 19.0 mm Less
Cutting Edge Thickness 0.63 in 16.0 mm Less
Height 15.3 ft³ 388.0 m³ Less
Length 28.5 in 724.0 mm Less
Operating Pressure 3336.0 psi 23000.0 kPa Less

Applications

Ideal for digging, dozing, clamping, back dragging, grading and leveling in construction, landscaping, industrial and demolition applications.

Excellent Clamping Force

Excellent clamping force lets you grasp large, irregularly shaped objects such as trees, loose stumps, brush, recycling debris and pipe, increasing the versatility of the machine.

Clam Jaw Opens a Full 89 Degrees

Bucket clam jaw opens a full 89 degrees, allowing the bucket to be used as a dozing blade.

Serrated Clam Side Edge

Serrated clam side edge provides a gripping surface to hold material.

GET Options

Base bucket also available with bolt-on cutting edge, bolt-on teeth and bolt-on tooth bar.

Overview

Accessories maximize the productivity of attachments

Name Description
PR190 Hydraulic Angle Power Box Rake Designed for clearing and preparing soil in landscape finishing applications.
PR184 Hydraulic Angle Power Box Rake Designed for clearing and preparing soil in landscape finishing applications.
1829 mm (72 in) Industrial Grapple Rake Designed to easily handle a wide array of bulky, irregularly shaped objects encountered in demolition, industrial, construction, recycling, storm debris clean-up, landscaping and other aggressive applications.
2137 mm (84 in) Industrial Grapple Rake Designed to easily handle a wide array of bulky, irregularly shaped objects encountered in demolition, industrial, construction, recycling, storm debris clean-up, landscaping and other aggressive applications.
LR18B Landscape Rake Cat® Landscape Rakes are used for scarifying the soil and collecting debris for easy removal.
LR15B Landscape Rake Cat® Landscape Rakes are used for scarifying the soil and collecting debris for easy removal.
