CAT® ELECTRIC ROPE SHOVELS




Cat® Electric Rope Shovels can load more material — more efficiently and more cost-effectively — than any other loading tool on the market. They combine immense payload capability with low maintenance requirements and high reliability to deliver the lowest cost-per-ton loading solution for long-life mines. With an operating life of 120,000 hours, they are a viable option for mines with estimated lives that meet or exceed a time frame of 20 years.

Support to maximize life — and profitability

The investment in an electric rope shovel is a long-term partnership. With the support of the global Cat dealer network along with Caterpillar’s technical resources, you can expect a long, productive life from your rope shovel. We help maximize availability and increase your return on investment through:

  • Support services (training, site assessment, parts planning, etc.)
  • Retrofits/machine overhaul
  • Service contracts
  • Replacement parts

of
Cat Electric Rope Shovels

ELECTRIC ROPE SHOVEL MODELS



WHY CHOOSE A CAT ELECTRIC ROPE SHOVEL?

Cat® Electric Rope Shovels combine immense payload capability with low maintenance requirements and high reliability to deliver the lowest cost-per-ton loading solution for long-life mines. A number of standard and optional features are available to take efficiency and productivity levels even higher. Please note that not all of the following features are available on all models. Contact your dealer for more information.


Our LatchFree™ Dipper System addresses the leading cause of rope shovel downtime, replacing the maintenance-intense latch assembly with a strong steel link assembly. The system’s unique arrangement makes it possible to locate the components on the dipper back. In addition, the components are designed and tested for a service interval of 3,000 hours. With the elimination of the maintenance associated with the latch assembly and an extended service interval, your rope shovel will spend more time loading, ultimately reducing your total cost of ownership.

Download PDF

of
Latchfree Dipper


The Operator Assist Technology Package includes enhancements that provide operator assist and machine self-protection without sacrificing productivity. Enhanced Motion Control protects the machine from operational practices that cause damage by intelligently controlling how motions are allowed to operate under certain conditions. And Machine Self Protection, a control system that detects and avoids machine self-collisions and, if a collision is imminent, arrests the machine motion to prevent or mitigate the collision.

Download PDF

of
Operator in cab

Engineered for the future, the Cat® Integrated Technology Package fully incorporates Cat Electronics and provides the platform to support technology expansion. The package features six standard technologies, including Machine Health, Vibration Monitoring, Cat Electronics, Payload Management, Bearing Temperature Monitor and Cycle Segmentation. The enhancements support higher productivity, improved reliability and increased security. The technology upgrade also provides a gateway for seamless integration of Cat MineStar™ Solutions.

Download PDF



The cab in Cat Electrical Rope Shovels includes updates that make operators safer, more comfortable and more productive.

  • Operators sit in a state-of-the-art, ergonomic seat, with a seat, armrest and footrest that adjust to perfectly fit wide range of body sizes.
  • Effortless operation and improved control response are made possible by the new joysticks with custom-designed ergonomic handles and “finger touch control” spring tension.
  • Intuitive and visually aesthetic display screens adjust for brightness and contrast to meet operator preferences.
  • The panoramic view from the operator's seat provides the best far-side visibility in the industry, plus cameras that feed five in-cab, overhead monitors augment line of sight and elevate situational awareness.
  • Access and egress are enhanced by the 45-degree rear-facing boarding stair; non-slip stairs, platforms and walkways; and dual-door design that facilitates cab entry and exit and enables a quick escape.
  • Fatigue-causing vibration is reduced thanks to bolstered support and stability of the extended machinery house underneath the isolator mounted cab.
of
Electric Rope Shovel Cab

ELECTRIC ROPE SHOVEL TECHNOLOGY SOLUTIONS

Operator Assist — Enhanced Motion Control

The Cat Operator Assist - Enhanced Motion Control system provides additional self-protection features without sacrificing productivity. Simplifying the dipper loading process allows operators to benefit from the enhanced machine capabilities.

Learn More
Enhanced Motion Control
Enhanced Motion Control

Cat MineStar™ Fleet

Fleet provides real-time machine tracking, assignment and productivity management, providing a comprehensive overview of all your asset operations from anywhere in the world.

Visit Page
MineStar Fleet
MineStar Fleet

Cat MineStar Terrain for Loading

Terrain for loading is a machine guidance system that delivers real-time data in the cab — on everything from bucket positioning and bench height to ore bodies and volume of material cut and filled.

Visit Page
MineStar Terrain
MineStar Terrain

Cat MineStar Health

Health delivers critical event-based machine condition and operating data for your entire fleet. It includes comprehensive equipment health and asset monitoring capabilities, with a wide range of diagnostic, analytic and reporting tools.

Visit Page
Cat MineStar Health
Cat MineStar Health

TOGETHER, WE'RE MINING BETTER

A Lasting Legacy

Flor Rivas, Caterpillar Inc., USA, celebrates 130 years of Caterpillar operations out of South Milwaukee in a Q&A with Will Owen, Editor of Global Mining Review.

Read Article

Alpha Coal West partners with Caterpillar to increase productivity

See how Caterpillar worked with Alpha Coal West to get more out of a 7495 Electric Rope Shovel at the company's Belle Ayr Mine in Wyoming.

Read Article

Maximizing Safety

Cat Electric Rope Shovels offer several key features that maximize the safety of those on and around the shovel/ Learn more about the safety features of the 7495 and 7495 HF.

Download PDF
Safety features
Safety features

Driving Efficiency and Lowering Cost Per Ton

Drawing on more than a century of rope shovel innovation, the 7495 and 7495 HF Electric Rope Shovels offer multiple standard feature upgrades that increase operating efficiency and lower cost per ton.

Read Article
7495
7495

The impact of change management on implementing a new technology

Learn more about how a proper change management strategy can increase the effectiveness of a new technology — and help you get more out of your investment.

Read Article
Read Article
Read Article

Successfully assembling one of the world’s largest machines

Watch as Cat dealer Ferreyros quickly and safely assembles a 7495 at a customer site in Peru.

Watch Video

Leading the Way in Efficiency and Reliability — And Continuing to Improve

Cat Electric Rope Shovels are built on a legacy of more than 140 years of success and innovation. Learn more about the history of these machines and how they came to lead the industry.

Read Article
Read Article
Read Article

Cat shovel reliability translates to high productivity

Join Cat Commercial Manager Ruth Haws as she discusses the reliability that makes Cat Electric Rope Shovels a powerful and productive choice for your mine.

Watch Video
Read Article
Read Article

Announcing Lower Works Design Enhancements

We talked to Global Mining Review about lower structure design enhancements that increase the reliability and lower the cost of ownership of our machines

Read Article
Read Article
Read Article

PARTS AND SERVICE

Key retrofits and upgrades to your Cat Electric Rope Shovel can help maximize your value. Thanks to feedback from customers, technicians and operators, Caterpillar makes continuous improvements to machine components to help improve uptime, reduce service and extend life, which help lower total cost of ownership. Talk to your Cat dealer for more information on these and other upgrades that could improve your operation and potentially lower your cost per ton.

Improved Swing Rack

Your swing rack is one of the hardest working pieces of your shovel. The more durable it is, the more reliable your entire machine will be. That's what inspired the latest iteration of swing racks for Cat Electric Rope Shovels. Designed with ease for retrofit in mind, this swing rack adds strength where it matters without adding unnecessary bulk.

Learn More
Improved Swing Rack
Improved Swing Rack

Propel Shaft Upgrade

Reducing the time your electric rope shovel is down for maintenance is critically important. Caterpillar's new propel drive system upgrade reduces downtime and lowers total cost of ownership by making servicing the propel drive shaft easier and less labor intense.

Learn More
Propel Shaft
Propel Shaft

Universal Handle

Compatible with 7395 and all 7495 series Electric Rope Shovels, this handle design increases component life, extending the change-out interval and ultimately reducing maintenance downtime.

Learn More
Universal Handle
Universal Handle

Fast Transfer Switch

The Cat integral fast propel transfer switch is a more responsive system that improves mode transfer as much as 75% — delivering more production hours and reducing service and costs due to downtime.

Learn More
Fast Transfer Switch
Fast Transfer Switch

Wet Disk Snubber

The revolutionary wet disk snubber design is maintenance and adjustment free for two years. Correlating with a dipper rebuild cycle, the set-and-forget snubber design works and wears with the dipper.

Learn More
Wet Disk Snubber
Wet Disk Snubber



Bearing Temperature Monitoring

Bearing temperature reduces the risk of major failures by alerting operators of high bearing temperatures. It also helps predict maintenance through bearing temperature trending.



AN IDEAL MATCH

Cat Electric Rope Shovels are designed for compatibility with Cat Trucks, allowing you to build an optimal loading and hauling solution.

Download PDF
