Overview

Designed to remove stumps in residential, commercial and agricultural settings.

Units:
Required Hydraulics High Flow XPS High Flow XPS Less
Cutting Wheel Diameter - With Teeth 22.0 in 547.0 mm Less
Cutting Depth - Below Ground 20.5 in 521.0 mm Less
Cutting Head Extension 11.0 in 280.0 mm Less
Cutting Head Speed at Maximum Flow 1230 rpm 1230 rpm Less
Cutting Head Swing Range 70 degrees 70 degrees Less
Cutting Height - Above Ground 18.5 in 470.0 mm Less
Cutting Wheel Width - With Teeth 3.3 in 83.0 mm Less
Cutting Width - Full Swing Range 60.0 in 1524.0 mm Less
Drive Method Gerotor Motor- Direct Gerotor Motor- Direct Less
Drive Shaft Torque at Maximum Pressure 346.0 lb/ft 469.0 N·m Less
Motor Displacement 6.2 in³ 100.0 cm³ Less
Optimal Hydraulic Pressure 207-310 bar (3000-4500 psi) 207-310 bar (3000-4500 psi) Less
Overall Height 32.0 in 813.0 mm Less
Overall Length 69.0 in 1737.0 mm Less
Overall Width 46.0 in 1175.0 mm Less
Required Hydraulic Flow 95-125 L/min (25-33 gpm) 95-125 L/min (25-33 gpm) Less
Weight 840.0 lb 400.0 kg Less
Number of Carbide Teeth per Cutting Wheel 32 32 Less

Heavy Duty Cutting Wheel

Heavy-duty cutting wheel and 32 bolt-on and replaceable carbide teeth provide maximum durability and cutting efficiency.

Adjustability

Adjustable cutting wheel swing, extension and depth for superior operator control.

Hydraulic Controls

Swing and extension are controlled hydraulically from the operator's compartment using an electro-hydraulic valve for greater productivity and swing cycle time efficiency.

Dual Height Pivoting Stand Feet

Heavy-duty, dual height, pivoting stand feet provide a stable platform when grinding. Feet are adjustable to compensate for specific machine coupler-to-ground height and tire diameters.

*Price listed is Manufacturer's Suggested Retail Price, this price does not include shipping and handling, expedite charges, taxes, dealer installation costs or other dealer charges. Dealers set actual prices, including invoicing currency. The MSRP displayed is for the region selected.
