Engine
| Engine Model | Cat® C27 Cat® C27 |
| Rated Engine Speed | 2000 r/min 2000 r/min |
| Gross Power - SAE J1995 | 825 hp 615 kW |
| Net Power - SAE J1349 | 727 hp 542 kW |
| Net Power - 80/1269/EEC | 727 hp 542 kW |
| Net Power - ISO 9249 | 727 hp 542 kW |
| Bore | 5.4 in 137 mm |
| Stroke | 6 in 152 mm |
| Displacement | 1648 in³ 27 l |
| Note (1) | Power rating applies at 2,000 rpm when tested under the specified condition for the specified standard. Power rating applies at 2,000 rpm when tested under the specified condition for the specified standard. |
| Note (2) | Ratings based on SAE J1995 standard air conditions of 25° C (77° F) and 100 kPa (29.61 Hg) barometer. Power based on fuel having API gravity of 35 at 16° C (60° F) and an LHV of 42 780 kJ/kg (18,390 BTU/lb) when engine used at 30° C (86° F). Ratings based on SAE J1995 standard air conditions of 25° C (77° F) and 100 kPa (29.61 Hg) barometer. Power based on fuel having API gravity of 35 at 16° C (60° F) and an LHV of 42 780 kJ/kg (18,390 BTU/lb) when engine used at 30° C (86° F). |
| Net Torque | 2874 ft-lb 3896 N·m |
| Peak Torque - Speed | 1300 r/min 1300 r/min |
| Note (3) | No engine derating required up to 3810 m (12,500 ft) for Tier 2 Equivalent. No engine derating required up to 3810 m (12,500 ft) for Tier 2 Equivalent. |
| Engine Power - ISO 14396 | 813 hp 607 kW |
