Pin Lock Couplers 10 Ton Mini Excavators, 450 Backhoe Loaders 1/2 Yard

Request A Price Click for Price

Key Specs

Weight: 244.7 lb; 111 kg

Width: 14.5 in; 368 mm

Length: 31.7 in; 806 mm

10 Ton Mini Excavators, 450 Backhoe Loaders 1/2 Yard
Change model

Overview

Utilitze one coupler to match existing work tool attachments with new Cat® machines or similarly-sized competitive machines.

Features At A Glance

Zinc plated engagement pin prevents corrosion, allowing for trouble free operation in harsh environments.

Standard locking pin with lanyard prevents loss and provides a placement holder when not in use.

Engagement points on coupler hooks are doubled plated for extending the life of the coupler. The increased contact area also provides additional stability for connected attachments. (450/310 versions only)

Fully compatible with Wain-Roy and Gannon-style buckets.

Product Specifications for 10 Ton Mini Excavators, 450 Backhoe Loaders 1/2 Yard

Weight	244.7 lb 111 kg
Width	14.5 in 368 mm
Length	31.7 in 806 mm
Overall Height	20.4 in 517 mm
Pin Diameter	60 mm/60 mm (2.4 in/2.4 in) 60 mm/60 mm (2.4 in/2.4 in)
Machine Class	10 Ton Mini Excavators, 450 Backhoe Loaders 10 Ton Mini Excavators, 450 Backhoe Loaders
Interface Type	Pin On Pin On
Required Hydraulics	None Required None Required

Product Specifications for 10 Ton Mini Excavators, 450 Backhoe Loaders 1/2 Yard

Download Print

Weight	244.7 lb 111 kg
Width	14.5 in 368 mm
Length	31.7 in 806 mm
Overall Height	20.4 in 517 mm
Pin Diameter	60 mm/60 mm (2.4 in/2.4 in) 60 mm/60 mm (2.4 in/2.4 in)
Machine Class	10 Ton Mini Excavators, 450 Backhoe Loaders 10 Ton Mini Excavators, 450 Backhoe Loaders
Interface Type	Pin On Pin On
Required Hydraulics	None Required None Required
