Multi-Purpose Buckets 1.34 m3 (1.75 yd3), Single Tilt Pin On, Bolt-On Cutting Edge, Extreme Duty

Request A Price Click for Price

Key Specs

Width: 96.7 in; 2457 mm

Height: 43.3 in; 1100 mm

Weight: 2866 lb; 1300 kg

1.34 m3 (1.75 yd3), Single Tilt Pin On, Bolt-On Cutting Edge, Extreme Duty
Change model

Overview

Excellent versatility for re-handling, clamping, dozing, grading, leveling and dumping.

Features At A Glance

Ideal for digging, dozing, clamping, back dragging, grading and leveling in construction, landscaping, industrial and demolition applications.

Excellent clamping force lets you grasp large, irregularly shaped objects such as trees, loose stumps, brush, recycling debris and pipe, increasing the versatility of the machine.

Base bucket also available with bolt-on cutting edge and bolt-on teeth.

2 lifting hooks (4 on Extreme Duty Buckets) allow the operator to lift objects using chain or straps.

See how wide you have your bucket open by looking at the sight guide - easily visible from the operators seat.

Reinforced side plates (Extreme Duty Buckets only) helps to increase lifespan of the bucket.

Product Specifications for 1.34 m3 (1.75 yd3), Single Tilt Pin On, Bolt-On Cutting Edge, Extreme Duty

Width	96.7 in 2457 mm
Height	43.3 in 1100 mm
Weight	2866 lb 1300 kg
Length	48.7 in 1237 mm
Capacity	1.75 yd³ 1.34 m³
Base Edge Thickness	0.8 in 20 mm
Cutting Edge Thickness	0.7 in 19 mm
Jaw Opening	31 in 787 mm
Clam Angle	83 degrees 83 degrees
Interface Type	Pin On Pin On

Product Specifications for 1.34 m3 (1.75 yd3), Single Tilt Pin On, Bolt-On Cutting Edge, Extreme Duty

Download Print

Width	96.7 in 2457 mm
Height	43.3 in 1100 mm
Weight	2866 lb 1300 kg
Length	48.7 in 1237 mm
Capacity	1.75 yd³ 1.34 m³
Base Edge Thickness	0.8 in 20 mm
Cutting Edge Thickness	0.7 in 19 mm
Jaw Opening	31 in 787 mm
Clam Angle	83 degrees 83 degrees
Interface Type	Pin On Pin On
