Hammers H45s

Name: H45s Hydraulic Hammer
Brand: Cat

New Used Rental

Request A Price Shop Now

Key Specs

Operating Weight - With Tool: 551.2 lb; 250 kg

Energy Class: 399.8 ft·lbf; 542 J

Machine Class: 1-3 Ton Mini Excavators; 1-3 Ton Mini Excavators

H45s
Change model

Overview

Used for demolition and construction applications.

Features At A Glance

Displaying 1-6 of 9

Application

Used in a wide range of construction and light demolition applications - such as breaking concrete sidewalks and driveways, pavement, roads, masonry, site prep and landscaping, and breaking frozen ground for utility repairs.

Silenced

Fully enclosed, silenced housing lowers overall noise level for a quieter, safer job site. Internal power cell is protected, designed and engineered to eliminate stress points.

Flat Top/Top Mount Style

Flat Top/Top Mount style provides a larger work area and excellent operator visibility with a common footprint and hole pattern for optimum versatility. Top-mount style increases impact power by keeping breaker force and stick force in line. A top-mount bracket will transfer back significantly less recoil and bending stress into the end of the stick, resulting in reduced impact on machine structures. Full complement of mounting brackets is available to suite coupler or pin-on preference.

Auto Shut Off (ASO)

ASO instantly stops the piston when breaking through material, preventing blank firing, a key contributor to hammer wear. Internal stresses are reduced, hammer is protected regardless of operator skill level.

Tri-Suspension System

Tri-Suspension system comprises the suspension jacket, the upper and lower buffers. Suspension aligns power cell and gives manageable, smooth performance.

Standing Height Grease Point

Standing height grease point makes required maintenance comfortable and easy to perform.

Fully enclosed, silenced housing lowers overall noise level for a quieter, safer job site. Internal power cell is protected, designed and engineered to eliminate stress points.

Tri-Suspension system comprises the suspension jacket, the upper and lower buffers. Suspension aligns power cell and gives manageable, smooth performance.

Standing height grease point makes required maintenance comfortable and easy to perform.

Gas ports and valves are easy to check and charge while hammer is mounted to machine.

Improved routing protects against force and dirt during impact, eliminating downtime.

Tools are heat-treated, matched to piston diameter and provide optimum mass to deliver full blow energy.

Product Specifications for H45s

Operating Weight - With Tool	551.2 lb 250 kg
Energy Class	399.8 ft·lbf 542 J
Machine Class	1-3 Ton Mini Excavators 1-3 Ton Mini Excavators
Tool Shaft Diameter	2 in 50 mm
Impact Frequency	780-1800 bpm 780-1800 bpm
Minimum Operating Pressure	1450.4 psi 10000 kPa
Minimum Carrier Weight	3309.1 lb 1501 kg
Optimal Hydraulic Flow	25-62 lpm (7-16 gpm) 25-62 lpm (7-16 gpm)
Overall Width	11.8 in 300 mm
Overall Length	12.2 in 311 mm
Overall Height	39.6 in 1006 mm
Height - Without Tool	29 in 737 mm
Sound Level	120 dB 120 dB
Mounting Bracket Size	Medium Medium

Product Specifications for H45s

Download Print

Operating Weight - With Tool	551.2 lb 250 kg
Energy Class	399.8 ft·lbf 542 J
Machine Class	1-3 Ton Mini Excavators 1-3 Ton Mini Excavators
Tool Shaft Diameter	2 in 50 mm
Impact Frequency	780-1800 bpm 780-1800 bpm
Minimum Operating Pressure	1450.4 psi 10000 kPa
Minimum Carrier Weight	3309.1 lb 1501 kg
Optimal Hydraulic Flow	25-62 lpm (7-16 gpm) 25-62 lpm (7-16 gpm)
Overall Width	11.8 in 300 mm
Overall Length	12.2 in 311 mm
Overall Height	39.6 in 1006 mm
Height - Without Tool	29 in 737 mm
Sound Level	120 dB 120 dB
Mounting Bracket Size	Medium Medium
