Studio Shot

Hammers B6 Side Mount

Starting MSRP*

$7,458.00 USD

Request A Price Click for Price

Key Specs

Operating Weight - With Tool
562.2 lb
255 kg
Energy Class
501.5 ft·lbf
680 J
Machine Class
5-6 Ton Mini Excavators
5-6 Ton Mini Excavators

Overview

Used for demolition and construction applications.

Product Specifications for B6 Side Mount

Operating Weight - With Tool 562.2 lb 255 kg
Energy Class 501.5 ft·lbf 680 J
Machine Class 5-6 Ton Mini Excavators 5-6 Ton Mini Excavators
Tool Shaft Diameter 2.7 in 68 mm
Impact Frequency 500-900 bpm 500-900 bpm
Minimum Operating Pressure 1775 psi 12238 kPa
Minimum Carrier Weight 8000.6 lb 3629 kg
Optimal Hydraulic Flow 40-70 lpm (10.6-18.5 gpm) 40-70 lpm (10.6-18.5 gpm)
Overall Width 14 in 355 mm
Overall Length 26.4 in 671 mm
Overall Height 53.3 in 1353 mm
Height - Without Tool 36.5 in 926 mm
Sound Level 128 dB 128 dB
Mounting Bracket Size Pin On Pin On

See how B6 Side Mount compares against frequently compared products.
