S Type Couplers S-45 Pin Grabber LCS 10 Ton

Starting MSRP*

$5,965.00 USD

Request A Price Click for Price

Key Specs

Weight
224.9 lb
102 kg
Lifting Hook Capacity
6613.9 lb
3000 kg
Width
13.9 in
353 mm

Overview

The S Type Coupler is a pin grabber style dedicated coupler. It ensures an exchangeability of tools within a fleet of machines with different platforms. Consistent tight fit to attachment, low offset, and reliability are the key features.

Product Specifications for S-45 Pin Grabber LCS 10 Ton

Weight 224.9 lb 102 kg
Lifting Hook Capacity 6613.9 lb 3000 kg
Width 13.9 in 353 mm
Overall Length 27.1 in 689 mm
Overall Height 13 in 330 mm
Pin Diameter 2.4 in 60 mm
Machine Class 10 Ton Mini Hydraulic Excavators 10 Ton Mini Hydraulic Excavators
Interface Type Pin On Pin On
Required Hydraulics Dedicated Factory Installed Dedicated Factory Installed
Maximum Operating Pressure 5076.3 psi 350 bar
Coupler Type S-45 Pin Grabber S-45 Pin Grabber

See how S-45 Pin Grabber LCS 10 Ton compares against frequently compared products.
