Hydraulic Connecting S Type Couplers Hydraulic Connecting S Type Coupler HCS65: 583-0661

Request A Price Find Dealer

Key Specs

Machine Class
14-20
14-20
Height
16.1 in
410 mm
Maximum Operating Pressure
5076 psi
350 bar

Overview

Cat® Hydraulic Connecting S Type Couplers connect to your machine's hydraulics and electronics giving you the ability to pick up an attachment with full functionality in seconds without leaving the cab. These couplers deliver the productivity and versatility benefits you expect from a coupler. Additionally, they bring safety to your people, equipment, and overall operation while increasing the life of the other attachments in your fleet.

Product Specifications for Hydraulic Connecting S Type Coupler HCS65: 583-0661

Machine Class 14-20 14-20
Weight 474 lb 215 kg
Lift Hook Capacity 5 ton (US) 5 ton (US)
Height 16.1 in 410 mm
Length 32.5 in 825 mm
Width 20 in 508 mm
Maximum Operating Pressure 5076 psi 350 bar
1/2" Hydraulic Connectors (Mounted) 2 2
1/2" Hydraulic Connector Flow 21 gal/min 79 l/min
3/4" Hydraulic Connectors (Mounted) 2 2
3/4" Hydraulic Connectors (Optional) 1 1
3/4" Hydraulic Connector Flow 59 gal/min 225 l/min

See how Hydraulic Connecting S Type Coupler HCS65: 583-0661 compares against frequently compared products.
